Engissol 2D Frame Analysis Dynamic Edition is an application specially built for structural analysis of frames, beams and trusses. It features linear and nonlinear static and dynamic analysis, allowing users to analyze modal responses under different loading conditions.
Engissol – 2D Frame Analysis Dynamic Edition Features
- Accuracy: Shear deformation elements of Timoshenko and second-order effects (Pi-Delta) have been implemented in the most accurate models.
- Customization: The user can create and define materials, cross-sections, and load cases.
- Efficiency: Models are easier to create because nodes are made from elements instead of the other way around.
- Comprehensive Library: The cross-sections of the standard structural components frames, trusses and beams are predefined and stored in the extensive library of materials and templates.
- Coordinate Systems: Different coordinate systems can be used for different positions of the force being applied.
- Overall Reporting: Simplified report calculation generation in multiple formats (PDF, DOC, XLS), which allows easy dissemination and evaluation of results.
- Dynamic Analysis: Permits response spectrum and time history analysis for seismic and dynamic loads.
2D Frame Analysis Dynamic Edition Overview
Image: Supports for Translational and Rotational Springs
